Description
Speaker Features
BEAUTIFUL SOUND AND BEAUTIFUL LOOK
JBL’s Stadium Series speakers – available in 2″, 3″, 5-1/4″,6-1/2″, 6″ x 8″, 4″ x 6″, 6″ x 9″, and 3/4″- bring iconic JBL sound that can only come from a 75-year pedigree of audio excellence to virtually any car on the road. Stadium’s Plus One™ fiberglass woofers deliver high-output, deep and robust bass. The high-resolution 3/4″ edge-driven textile dome tweeters deliver soaring highs up to 40kHz. 2″ and 3″ midranges are available to upgrade two-way component systems into three-way. The compact 3″ midrange speakers also offer a perfect plug-and-play solution with low frequency response to 300Hz, and high sensitivity.
General Specifications
Power Handling
120Wrms, 360W peak
Sensitivity (@ 2.83V)
94dB
Frequency Response
35Hz – 40kHz
Impedance
3.0ohms
What’s in the box?
2 x STADIUM 962M Speakers
2 x Grilles
2 x Spacers
2 x Foam gaskets
8 x Screws
8 x Speed clips
2 x JBL logo badges
2 x Brand stickers
1 x Owner’s manual
Speaker Specifications
| SPEAKER SPECIFICATIONS | |||||
|---|---|---|---|---|---|
|
JBL STADIUM962M Full-Range Coaxial Speaker |
|||||
| GENERAL | |||||
| Speaker Design | 3-Way | ||||
| DC Resistance (Ω) | 3 Ohm (Ω) | ||||
| Peak Power (Watts) | 360W | ||||
| Continuous Power (RMS) | 120W | ||||
| Sensitivity | 94dB | ||||
| Effective Frequency Range | 35-40,000 Hz | ||||
| MOUNTING INFORMATION | |||||
| Mounting Hole Diameter | 7 3/4 X 10 19/32 (196.85 mm X 268.62 mm) | ||||
| Top Mount Depth | 1-3/16″ | ||||
| Bottom Mount Depth | 3-5/32″ | ||||
| Grille | Yes | ||||
| Warranty | 1 Year | ||||
