Description
Speaker Features
Speaker Features
HERTZ – DCX100.3
- Large motor assembly for moblie voice coil control
- Pure copper voice coil, wound on Conex former, for maximum lightness
- Water-repellent treated paper cone
- TPU surround, for wide excursion and resonance damping
- REN Neodymium tweeter with PEI dome, for compactness and energy at high frequencies
- DIN size basket protected by abrasion-proof dust paint
- Tin-plated, high current terminals
- Silver-plated lead wires for maximum reliability and conductivity
- Butyl rubber protective cover, against crashes and abrasions
- Epoxy glue for basket and motor system provides perfect coupling
- Low carbon content plates for maximum magnetic permeability and high heat dissipation
Speaker Specifications
| SPEAKER SPECIFICATIONS | |||||
|---|---|---|---|---|---|
|
Hertz DCX100.3 Full-Range Speaker |
|||||
| GENERAL | |||||
| Speaker Design | 2-Way | ||||
| Woofer | Woofer Size | 4 | |||
| Woofer Cone Material | Paper | ||||
| Woofer Surround Material | Thermoplastic Polyurethane | ||||
| Tweeter | Tweeter Size | 3/4 | |||
| Tweeter Dome Material | PEI | ||||
| Tweeter Design | Dome | ||||
| DC Resistance (Ω) | 4 Ohm (Ω) | ||||
| Peak Power (Watts) | 60W | ||||
| Continuous Power (RMS) | 30W | ||||
| Sensitivity | 92dB | ||||
| Effective Frequency Range | 70 – 21kHz | ||||
| MOUNTING INFORMATION | |||||
| Mounting Hole Diameter | 3-7/10″ (93.98 mm) | ||||
| Top Mount Depth | 1-7/10″ | ||||
| Bottom Mount Depth | 3/10″ | ||||
| Grille | No | ||||
| Warranty | 2 Year | ||||
